VLAN & VXLAN on MikroTik with LABS (RouterOS v6 & v7)

Understand and configure VLAN and VXLAN on different MikroTik products (RB, CRS & CSS) using RouterOS and SwOS

What you'll learn

  • Understand why we need VLAN's in our networks
  • Understand the different between Trunk and access ports
  • Configure VLAN's on RouterOS (prior version 6.41)
  • Configure VLAN's on RouterOS using the Switch Board
  • Configure VLAN's on RouterOS without using the Switch Board
  • Understand and configure Q-inQ
  • Configure VLAN's on MikroTik Cloud Smart Switch (CSS) using SwOS
  • Configure VLAN's on MikroTik Cloud Router Switch (CRS)
  • Configure VLAN Management in CSS Switches
  • Configure VLAN Management on CRS Switches
  • Configure VXLAN on RouterOS v7
  • Configure VLAN over EOIP Tunnel on RouterOS v7
  • Configure Port-Based VLAN on CRS3xx series using RouterOS v7
  • Configure MAC-Based VLAN on CRS3xx series using RouterOS v7

Requirements

  • Basic network knoweldge
  • Knowledge of the TCP/IP protocol
Description

Configuring VLAN's on MikroTik products can be a challenge. There are different ways to create VLAN's and the configuration differs from a MikroTik product to another.

For this reason, I have created this course to show you all possible ways of creating VLAN's on MikroTik products. This will include configure VLAN's on RouterBoards using the RouterOS, on CRS switches using RouterOS, as well as on MikroTik CSS switches using SwOS.

Finding information on the internet of creating VLAN's on MikroTik products is very limited, so this course can be used as a reference in case you want to create VLAN's in your production network.

To be able to practice all LABS of this course, you require to have physical hardwares as following:

  • Internet service
  • 2 x RB such as RB941 or RB951
  • 1 x CSS switch such as RB260
  • 1 x CRS switch such as CRS109
  • 2 x CRS3xx series switches such as CRS326
  • 5 x UTP cables
  • 1 x PC

I hope you will enjoy this course and I will see you inside.

Who this course is for:
  • Students who wants to understand how VLAN's work and how to apply them on MikroTik products
  • MikroTik engineers who want to implement VLAN's in their production networks


Your Instructor


Maher Haddad
Maher Haddad

Hello everyone. My name is Maher Haddad and I am a Certified MikroTik Trainer, Cisco Authorized Instructor and LigoWave Authorized Trainer.

I have decided to make this online school to share my knowledge to the community. All my courses are based on theory and hands-on LABS so you can practise while learning.

More than 100K happy students have joined mynetworktraining.com up to year 2022.


I hope you will enjoy watching my courses.


Course Curriculum


  What is Virtual Local Area Network (VLAN)
Available in days
days after you enroll
  Configuring VLAN's on MikroTik RouterBoard products
Available in days
days after you enroll
  Configuring VLAN's on MikroTik Cloud Router Switch (CRS)
Available in days
days after you enroll

Frequently Asked Questions


When does the course start and finish?
The course starts now and never ends! It is a completely self-paced online course - you decide when you start and when you finish.
How long do I have access to the course?
After enrolling to the membership, you have unlimited access to this course for as long as your membership is valid - across any and all devices you own.
What if I am unhappy with the course?
We would never want you to be unhappy! If you are unsatisfied with your purchase, contact us in the first 14 days and we will give you a full refund.

Get started now!
